Specifications
Basic Parameter
Model
ZHUOP RNA08C
Frequency Range
840 MHz–960 MHz
Air Interface Protocol
EPCglobal Class 1 Gen 2 / ISO/IEC 18000-63; supports GB/T 29768 and GJB 7377.1
Integrated Antenna
8 dBi Circularly Polarized UHF RFID Antenna
Operating Voltage
DC 9–24 V; Standard 12 V Power Adapter Included
Status Indication
LED Indicators and Buzzer
RF Performance
RF Output Power
Up to 33 dBm ±1 dB
Frequency Mode
Frequency-Hopping Spread Spectrum (FHSS) or Fixed-Frequency Mode, Software Configurable
Receiver Sensitivity
Up to −78 dBm
Maximum Read Range
Up to 10 m
Maximum Write Range
Up to 5 m
Tag Read Rate
Up to 400 Tags/s
Multi-Tag Processing Capacity
Up to 600 Tags within 3 Seconds
Continuous Read PerformanceTag Read Rate
Over 95% Success Rate for 100 Consecutive Reads in an Interference-Free Environment
Continuous Write Performance
Over 90% Success Rate for 100 Consecutive Writes
Communication & Development
Communication Interfaces
RS-232, RS-485, Wiegand 26/34, RJ45 Ethernet and Wi-Fi
RS-232 Baud Rate
9,600 / 19,200 / 115,200 bps (Default) / 460,800 bps
Ethernet Interface
10/100 Mbps Auto-Negotiation
GPIO
2 Optically Isolated Inputs and 2 Relay Outputs
Relay Contact Rating
DC 30 V/1 A or AC 125 V/0.75 A
Development SupportSupport for 2D
API and SDK Provided
Supported Languages
C# and Java
Mechanical Specifications
Dimensions
225 × 225 × 55.5 mm
Enclosure Material
Engineering-Grade Plastic Housing with Aluminum Rear Cover
Illustration
