Specifications
Basic Parameter
Model
ZHUOP RNA06A
Frequency Range
840 MHz–960 MHz
Air Interface Protocol
ISO 18000-6C / EPC C1G2; supports GB/T 29768 and GJB 7377.1 protocols
Integrated Antenna
6 dBi Circularly Polarized Antenna
Operating Voltage
DC 9–24 V
Status Indication
LED Indicators and Buzzer
RF Performance
RF Output Power
Up to 33 dBm ±1 dB
Frequency Mode
Frequency-Hopping Spread Spectrum (FHSS) or Fixed-Frequency Mode, Software Configurable
Receiver Sensitivity
Up to −78 dBm
Maximum Read Range
Up to 6 m
Maximum Write Range
Up to 3 m
Tag Read Rate
Up to 400 Tags/s
Multi-Tag Processing Capacity
Up to 600 Tags within 3 Seconds
Continuous Read PerformanceTag Read Rate
Over 95% Success Rate for 100 Consecutive Reads in an Interference-Free Environment
Continuous Write Performance
Over 90% Success Rate for 100 Consecutive Writes
Communication & Development
Communication Interfaces
RS-232 and Ethernet
RS-232 Baud Rate
9,600 / 19,200 / 115,200 bps Default / 460,800 bps
Ethernet Interface
10/100 Mbps Auto-Negotiation
Development SupportSupport for 2D
API and SDK Provided
Supported Languages
C# and Java
Mechanical Specifications
Dimensions
180 × 180 × 49 mm
Enclosure Material
Engineering-Grade Plastic Housing with Metal Rear Cover
Product Configuration
Integrated UHF RFID Reader with Built-in Antenna
Illustration
