Specifications
RF & IC Specifications
Protocol
EPC Class 1 Gen 2 / ISO 18000-6C
Frequency
902–928 MHz or 865–868 MHz
Chip
Impinj M781
EPC Memory
128 bit
User Memory
512 bit
Read / Write
Yes
Polarization
Linear
RF Performance Consistency
100% tested with Voyantic Tagformance or Tagsurance
Data & Service Life
Data Retention
50 years
Warranty
1 year
Physical Specifications
Material
ABS / ASA
Color
Orange
Dimensions
85 × 20 × 11 mm (3.346 × 0.787 × 0.433 in)
Mounting Hole Diameter
4.03 mm
Mounting Hole Center Distance
76.5 mm
Installation
Screw, rivet, glue, or optional 3M 300LSE tape
Weight
10 g
Packaging
Carton
Environmental & Durability
Operating Temperature
-25°C to +70°C
Storage Temperature
-40°C to +70°C
Storage Humidity
5%–95%
Drop Test
Passed 200 drops from a height of 1 m
Alcohol Resistance
Passed wiping test with 95% alcohol
Gasoline Resistance
Passed wiping test with No. 92 gasoline
Temperature Shock Test
-40°C to +70°C, 7 cycles, 48 hours total; passed
RoHS
Compatible; SGS certified
IP Rating
IP67
Read Performance
Read Range on Metal
Up to 6 m
Fixed Reader Test Setup
4 W EIRP, Alien 9900 reader
