Specifications
RF & IC Specifications
Protocol
EPC Class 1 Gen 2 / ISO 18000-6C
Frequency
902–928 MHz or 865–868 MHz
Chip
Impinj M730
EPC Memory
128 bit
User Memory
0 bit
Read / Write
Yes
Polarization
Linear
RF Performance Consistency
100% tested with Voyantic Tagformance
Data & Service Life
Data Retention
50 years
Warranty
1 year
Physical Specifications
Material
ABS
Color
Light blue
Dimensions
65.5 × 30.3 × 5 mm (2.578 × 1.192 × 0.196 in)
Bottom Curvature Radius
R100 outer profile; R105 inner profile shown in drawing
Installation
Super glue or 3M 300LSE double-sided adhesive
Weight
Approx. 13.5 g
Packaging
Carton
Optional Processing
Laser coding, logo silk-screen printing, or pre-encoding
Environmental & Durability
Operating Temperature
-25°C to +73°C
Storage Temperature
-30°C to +73°C
Humidity
5%–95%
Drop Test
Passed 200 drops from a height of 1 m
Alcohol Resistance
Passed wiping test with 95% alcohol
Gasoline Resistance
Passed wiping test with No. 92 gasoline
Temperature Cycle Test
-30°C to +80°C, 7 cycles, 48 hours total
RoHS
Material certified by SGS
IP Rating
IP67
Read Performance
Fixed Reader Range on Metal
Up to 7 m
Fixed Reader Test Setup
4 W EIRP, Alien 9900 reader; results may vary
Handheld Reader Range on Metal
Up to 4.5 m
Handheld Test Setup
Alien 9011 in outdoor open space; results may vary
