Specifications
RF & IC Specifications
Protocol
EPC Class 1 Gen 2 / ISO 18000-6C
Frequency
902–928 MHz or 865–868 MHz
Chip
Impinj M781
EPC Memory
128 bit
User Memory
512 bit
Read / Write
Yes
Polarization
Linear
RF Performance Consistency
100% tested with Voyantic Tagformance
Data & Service Life
Data Retention
50 years
Warranty
1 year
Physical Specifications
Material
ABS or strong weather-resistant polymer
Color
Orange
Dimensions
51 × 51 × 12.6 mm (2.01 × 2.01 × 0.49 in)
Installation
Double-sided tape, super glue, screws, or aluminum rivets
Weight
Approx. 26 g
Packaging
Anti-static bag and carton
Optional Processing
Pre-writing, surface laser processing, UV pattern processing, silk-screen printing, or pad printing
Environmental & Durability
Operating Temperature
-25°C to +73°C
Storage Temperature
-40°C to +73°C
Humidity
5%–95%
Drop Test
Passed 200 drops from a height of 1 m
Alcohol Resistance
Passed wiping test with 95% alcohol
Gasoline Resistance
Passed wiping test with No. 92 gasoline
Temperature Cycle Test
-40°C to +73°C, 7 cycles, 48 hours total
RoHS
Material certified by SGS
IP Rating
IP67
Read Performance
Fixed Reader Range on Metal
Over 10 m at 4 W EIRP
Handheld Reader Range on Metal
Over 5 m
Handheld Test Setup
R2000 RF module, source-listed +33 dBi power and 4 dBi antenna in outdoor open space; results may vary by reader
