Specifications
RF & IC Specifications
Protocol
ISO 15693 / ISO 18000-3
Frequency
13.56 MHz
Chip Options
NXP ICODE SLIX or Fujitsu MB89R118C1-DIAP15
ICODE SLIX Memory
User 896 bits (112 bytes); UID 64 bits
Fujitsu Memory
FRAM, 2 KB
Read / Write
Yes
Read Range
4 cm; results may vary by reader
Data & Service Life
Data Retention
50 years
Physical Specifications
Material
PPS
Dimensions
Diameter 15 mm x 2.8 mm thick (±0.2 mm)
Weight
Approximately 0.8 g per piece
Color
Black or gray
Packaging
Anti-static bag and carton
Environmental & Durability
Operating Temperature
-25°C to +110°C
Storage Temperature
-40°C to +130°C
Short-Term Heat Resistance
180°C for 2 minutes
Humidity
5% to 95%
Drop Test
Passed 200 drops from a height of 1 m
Alcohol Resistance
Passed 95% alcohol concentration test
Gasoline Resistance
Passed No. 92 gasoline wipe test
Temperature Cycle Test
-40°C to +130°C, 7 cycles over 2 consecutive days; passed
RoHS
Passed; material SGS certified
IP Rating
IP68
Pressure Resistance
42 bar
Options & Order Numbers
Optional Processing
Surface laser marking of UID number
ICODE SLIX Order Number
10-Pls1515-Slix
Fujitsu Order Number
10-Pls1515-MB89R118C1
