Specifications
RF & IC Specifications
Protocol
EPC Class 1 Gen 2 / ISO 18000-6C
Frequency
902-928 MHz; EU-band version and custom tuning available
Chip
NXP UCODE 8
EPC Memory
128 bits
Read / Write
Yes
Polarization
Linear
Data & Service Life
Data Retention
50 years
Warranty
1 year
Physical Specifications
Material
PI
Color
Earth yellow
Dimensions
49 x 9 mm
Weight
1 g per piece
Installation
Embed in silicone, plastic, rubber or other non-metal products
Packaging
Carton
Environmental & Durability
Operating Temperature
-40°C to +85°C
Storage Temperature
-40°C to +230°C
Storage Humidity
5% to 95%
Drop Test
Passed 200 drops from a height of 1 m
Alcohol Resistance
Passed 95% alcohol concentration test
Gasoline Resistance
Passed No. 92 gasoline wipe test
Temperature Cycle Test
-40°C to +150°C, 7 cycles over 2 consecutive days; passed
RoHS
Passed; material SGS certified
IP Rating
IP63
Read Performance
Fixed Reader Range
Over 12 m under the specified test conditions
Handheld Reader Range
Over 3 m using an Alien 9011 handheld reader in an open outdoor area
RF Performance Consistency
100% tested and passed using a Voyantic Tagformance system
