Specifications
RF & IC Specifications
Protocol
EPC Class 1 Gen 2 / ISO 18000-6C
Frequency
902-928 MHz or 865-868 MHz
Chip
Impinj M730
EPC Memory
128 bits
User Memory
0 bits
Read / Write
Yes
Power Supply
Passive
Data & Service Life
Data Retention
20 years
Warranty
1 year
Storage Conditions
1 year at +20°C / 50% relative humidity
Physical Specifications
Surface Material
AV PET
Color
Light white
Dimensions
30 x 12 x 1.23 mm (1.18 x 0.47 x 0.04 in)
Installation
3M tape
Packaging
Anti-static bag; 800 pieces per small carton and 6,400 pieces per master carton
Minimum Curved Surface Diameter
50 mm
Environmental & Durability
Operating Temperature
-40°C to +75°C (-104°F to +167°F)
Storage Humidity
5% to 95%
Alcohol Resistance
Passed 95% alcohol wipe test after full-resin ribbon printing
Temperature Cycle Test
-40°C to +75°C, 7 cycles over 48 hours; passed
Double 85 Test
+75°C and 85% humidity for 148 hours; passed
RoHS / SVHC
Compatible
IP Rating
IP68
RF Performance Consistency
100% tested using Voyantic Tagsurance
Read Performance
Read Range on Metal
Up to 1.3 m
Read Test Setup
Handheld reader with Impinj R2000 RF module, +30 dBm power and 4 dBi antenna
Printing Compatibility
Compatible Printers
Zebra, SATO, Toshiba and Postek RFID printers
Print Ribbon
Full resin carbon ribbon
