— 5.5 dBi gain, 100° beam width, IP67 protection

D915C5L132 – 5.5 dBi UHF RFID Directional Antenna

The D915C5L132 is a compact UHF RFID directional antenna designed for reliable RFID reading applications. Operating at 902–928 MHz, it provides 5.5 dBi gain with circular polarization, a 100° horizontal and vertical beam width, and VSWR ≤1.3. With IP67 protection, 50 W maximum input power, N-Female connector and an operating temperature range of -40°C to +70°C, it is suitable for industrial, warehouse and outdoor RFID deployments.

Description

Specifications

Basic Parameter

Product Model

D915C5L132

Frequency Range

902–928 MHz

Gain

5.5 dBi

Polarization

Circular Polarization

Dimensions

132 × 132 × 18 mm

Net Weight

0.35 kg

Electrical Performance

Beam Width

Hor: 100° / Ver: 100°

VSWR

≤ 1.3

Impedance

50 Ω

Axial Ratio

≤ 2 dB

Maximum Power

50 W

Lightning Protection

DC Grounding

Connector

N-Female

Connector Position

Bottom Straight Exit

Frequency Band

FCC 902–928 MHz

Mechanical & Environmental

Radome Material

PC + ABS

Radome Color

White

Protection Rating

IP67

Operating Temperature

-40°C to +70°C

Antenna Thickness

18 mm

Antenna Size

132 × 132 mm

Polarization

Circular Polarization

Connector Type

N-Female

Product Highlights

Design

Compact Directional Antenna

Environmental Durability

IP67 / -40°C to +70°C
