Specifications
RFID Specifications
Model
10-Laundry7015
Product Type
UHF RFID laundry tag
EPC Standard
EPC Class 1 Gen 2
ISO Standard
ISO 18000-6C
Frequency
845–950 MHz
Chip
NXP Ucode9
EPC Memory
96 bit
User Memory
0 bit
Read / Write
Yes
Data Storage
20 years
Power
Passive
Read Range
0–13 m (up to 13 m)
Polarization
Linear (listed as “Liner” in source)
Industrial Laundry Performance
Service Life
200 wash cycles or 3 years from shipping date, whichever comes first
Washing
90°C (194°F), 15 minutes, 200 cycles
Pre-drying
180°C (356°F), 30 minutes, 200 cycles
Ironing
180°C (356°F), 12 seconds, 200 cycles
Sterilization
135°C (275°F), 20 minutes, 200 cycles
Mechanical Resistance
60 bar
Applications
Industrial Washing Management
Supported
Textile Management
Supported
Textile Leasing Management
Supported
Personnel Positioning Management
Supported
Attendance Management
Supported
Fire Equipment Management
Supported
Ski Facility Management
Supported
Plastic Tray Management
Supported
Physical Specifications
Material
Textile
Dimensions
70 × 15 × 1.5 mm (2.75 × 0.59 × 0.06 in)
Weight
Approx. 0.6 g per piece
Color
White
Installation
Sewing or placing in a pouch
Chemical Resistance
Normal common chemicals used in washing processes
Packaging
Antistatic Bag
500 pieces per bag
Carton Dimensions
46 × 22 × 29 cm
Carton Weight
6.3 kg
Carton Quantity
10,000 pieces per carton
Certifications
RoHS
Listed
SVHC
Listed
OEKO-TEX Standard 100
Class II
GB18401
Listed
EECC
Listed in source
Advantages & Options
Function Testing
100% function tested
Laundry Validation
Tested in real-world laundries
Wash-cycle Guarantee
200 cycles with water extractors up to 60 bar
Size Advantage
Small size
Pre-encoding
Available
Laser TID
Available
EPC Customization
Available
Serial Number
Available
Logo Customization
Available
