Specifications
RFID Specifications
EPC Standard
EPC Class 1 Gen 2
ISO Standard
ISO 18000-6C
Frequency
845–950 MHz
NXP Ucode9 Chip Option
Available
NXP Ucode9 EPC Memory
96 bit
NXP Ucode9 User Memory
0 bit
Read / Write
Yes
Data Storage
20 years
Power
Passive
Read Range
0–13 m (up to 13 m)
Polarization
Linear (listed as ‘Liner’ in source)
Industrial Laundry Performance
Service Life
200 wash cycles or 3 years from shipping date, whichever comes first
Washing
90°C (194°F), 15 minutes, 200 cycles
Pre-drying
180°C (356°F), 30 minutes, 200 cycles
Ironing
180°C (356°F), 12 seconds, 200 cycles
Sterilization
135°C (275°F), 20 minutes, 200 cycles
Mechanical Resistance
60 bar
Physical Specifications
Material
Textile
Dimensions
70 × 15 × 1.5 mm (2.75 × 0.59 × 0.06 in)
Weight
Approx. 0.6 g per piece
Color
White
Sewing
Available
Pouch Installation
Available
Chemical Resistance
Normal common chemicals used in washing processes
Packaging
Antistatic Bag
500 pieces per bag
Carton Dimensions
46 × 22 × 29 cm
Carton Weight
6.3 kg
Carton Quantity
10,000 pieces
Certifications
RoHS
Listed
SVHC
Listed
MRI
1.5T and 3T listed in source
OEKO-TEX Standard 100
Class II
GB18401
Listed
EECC
Listed in source
