Specifications
RFID Specifications
EPC Standard
EPC Class 1 Gen 2
ISO Standard
ISO 18000-6C
Frequency
860–940 MHz
Chip
Impinj M750
EPC Memory
96 bit
User Memory
32 bit
Read / Write
Yes
Data Storage
20 years
Power
Passive
Read Range
0–13 m (up to 13 m)
Polarization
Linear (listed as ‘Liner’ in source)
Industrial Laundry Performance
Service Life
300 wash cycles or 3 years from shipping date, whichever comes first
Washing
90°C (194°F), 15 minutes, 300 cycles
Pre-drying
180°C (356°F), 30 minutes, 300 cycles
Ironing
180°C (356°F), 12 seconds, 300 cycles
Sterilization
135°C (275°F), 20 minutes, 300 cycles
Mechanical Resistance
60 bar
Physical Specifications
Material
Textile
Dimensions
70 × 10 × 1.5 mm (2.75 × 0.39 × 0.06 in)
Weight
Approx. 0.4 g per piece
Color
White
Sewing
Available
Pouch Installation
Available
Chemical Resistance
Normal common chemicals used in washing processes
Packaging
Antistatic Bag
500 pieces per bag
Carton Dimensions
46 × 22 × 29 cm
Carton Weight
4.9 kg
Carton Quantity
10,000 pieces
Certifications
RoHS
Listed
SVHC
Listed
OEKO-TEX Standard 100
Class II
GB18401
Listed
EECC
Listed in source
