Specifications
RFID Specifications
EPC Standard
EPC Class 1 Gen 2
ISO Standard
ISO 18000-6C
Frequency
902–928 MHz
Chip
Impinj M4QT
EPC Memory
128 bit
User Memory
512 bit
Read / Write
Yes
Data Storage
50 years
Fixed Reader Distance
0–6 m
Handheld Reader Distance
0–3 m
Polarization
Linear (listed as ‘Liner’ in source)
Environmental & Reliability
Service Life
1 year
Operating Temperature
-40°C to +85°C (PDF prints -104°F to +185°F; Fahrenheit value is inconsistent)
Storage Temperature
-45°C to +140°C (PDF prints -113°F to +284°F; Fahrenheit value is inconsistent)
Storage Humidity
5%–95%
IP Rating
IP68
Drop Test
Passed 200 drops from 1 m
Alcohol Test
Passed 95% alcohol concentration test
Gasoline Test
Passed ‘92 gasoline wipe’ as printed in source
Temperature Cycle Test
-40°C to +140°C, 7 cycles over 2 days
RF Performance Consistency
100% tested and passed Voyantic Tagformance test
Physical Specifications
Material
Silicone
Color
White
Dimensions
55 × 12 × 2.5 mm (2.16 × 0.47 × 0.09 in)
Weight
Approx. 2 g per piece
Installation
Placing in a pouch
Packaging
Package
Carton package
Certifications
RoHS
Listed
